5 Ltr, 25 Ltr
RXSOL Pickling Liquid - Performs multiple cleaning action such as degreaser by removing oil effectively and also providing protective coating to keep rust free surface. Uses of Pickling liquid RXSOL helps to keep metal surface as priming after welding which can be used for Electrostatic Painting and powder coating. Also Uses of Pickling Liquid RXSOL helps to eliminate uses of all hazardous chemicals such as solvent, Acid, Phophate, Chromate etc. And its uses also helps to avoid sand scrubbing, blassting for metal surface preparation.
The Pickling Dip Liquid fluid is recommended for immersion pickling of small objects and for pickling surfaces that are time-consuming to brush or spray pickle. It can also be used for circulation pickling of pipe systems. Pickling Liquid reduced the Re-work to Zero, saving a lot of labor, time & cost.
Standard grades, such as 304 and 316: Mix 1 part Pickling Dip Liquid into 3 patrs of water. A further dilution can be done if longer pickling timesc an be accepted. High-alloyed grades, such as duplex grades (2205) and austenitic grades (904 L) for use in severe corrosive conditions: Mix 1 part of Pickling Dip Liquid in to 2 parts of water. Very high alloyed grades, such as super-austenitic (254 SMO) and super-duplex (2507) grades: Mix 1 part of Pickling Dip Liquid into 1 part of water.
1. Before first time use. Make the solution by adding the Pickling Dip Liquid to the water, not the other way round! The proportions depend on the steel to be pickled.
2. Pre-clean the objects to remove grease and oil before pickling by using RXSOL DEGREASER.
3. Place the product in the pickling bath.
4. Allow sufficient pickling time. Use 5 min to 4 hours depending on temperature, steel grade, condition of the Pickling Dip Liquid etc.
5. Rinse with high-pressure water jet after pickling.
6. Analyse the Pickling Dip Liquid content of acids and free metals regularly to maintain optimal Pickling Dip Liquid composition.
Features & Benefit :
-
Restores stainless steel surfaces that have been damaged during fabrication operations such as welding, forming, cutting and blasting. It removes weld oxides, the underlying chromium-depleted layer and other defects that may cause local corrosion.
- Working life; the bath fluid is consumed during usage and the effective working life of the bath fluid is determined by the amount of acids and dissolved metals. The bath fluid should hence be analysed regularly, and new acid should be added when needed in order to obtain an optimal pickling result. Avesta Finishing Chemicals may assist with this analysis service.
Storage:
Pickling Dip Liquid should be stored indoors at room temperature. Containers must be kept properly closed, in an upright position and inaccessible to unauthorised persons. The products are perishable and should not be kept in storage longer than necessary. They have a maximum shelf life of two years when stored at room temperature. Exposure to higher temperatures may reduce shelf life
Handling :
Protective clothing. In general users should wear acid-resistant overalls, gloves and rubber boots. Face visor should be used and, if necessary, suitable respiratory protective devices. Special conditions may apply from one country to another. Refer our Material Safety Data Sheets.
|
Physical state at 20oC |
: |
Colourless liquid |
|
Boiling point |
: |
80-100oC |
|
Flash point / Explosion properties |
: |
Not applicable |
|
Specific temperatures: |
: |
Solid-fluid 40oC, Fluid-gas 50-60oC (nitric fumes) |
|
Vapour pressure at 20oC |
: |
|
|
pH |
: |
0 at 20oC |
|
Density |
: |
1.1-1.4 g/cm3 at 20oC |
|
Solubility in water at 20oC |
: |
100 weight % |
MATERIALS AND CONDITIONS TO AVOID INCOMPATIBILITY : Caustics, Amines, Alkanolamines, Aldehydes, strong Oxidizing agents and Chlorinated compounds.
Pickling Liquid having multiple utility, Its multi directional uses have 8 products properties as follows:
1. Degreasing Action as METAL SURFACE CLEANER – Removes light mill oil and water based cutting fluid
2. RUST Cleaner as RUST REMOVER – Removes surface rust completely
3. Corrosion Inhibitor as RUST INHIBITOR – Provides years of indoor Rust Protection (more than 6 to 8 years).
4. RUST CONVERTER – Converts 100% Rust and provide Protective coating
5. Clean Surface for WELDING PREPARATION as a ANTI-SPATTER
6. Works as PRE-TREATMENT and CONVERSION COATING – Prepares the metal surface for Priming, Painting, Electro-static painting, Powder Coating etc. Also can be used with High Temperature Paint & Coatings(operating temperature up to 2000⁰F)
7. Resisit further oxidation and acts as a SEALER RX Pickling Liquid coating seals by itself and stops further oxidation
8. RX Pickling Liquid effectively acts as a DE-SCALER (MILL SCALE, HEAT SCALE)– One Step De-scaling/De-Rusting removes mill scale & rust, provide a conversion coating and Seal the coating.
SAVING A LOT OF LABOR, TIME & COST, ALL IN SIMPLE ONE STEP PROCESS. ALSO ENVIRONMENTALLY SAFE, NON-HAZARDOUS, WATER BASED & READY TO USE PRODUCT.
Pickling Dip Liquid is Water based Conversion coating, Rust/Heat scale remover, Rust inhibitor, & Recommended Use Rust converter, Effectively used for Weld prep., Anti-spatter and a complete metal surface preparation/pre-treatment compound for ferrous & non-ferrous metal.
Pickling Dip Liquid Savings:
1) “Value Added Product” which Saves a lot of labor, time, cost & energy by eliminating one or more traditional steps during metal surface preparation for welding and finishing (priming, painting, powder coating etc.)
2) Very large coverage (around 1600 sq. ft. per gallon
3) Unit Cost is few cents per sq. ft. along with a very less labor time.
4) Long Shelf Life – No Wastage
5) Solves all quality failures such as, Welding failure, Adhesion failure as well as solving the Rusting problem completely.
Pickling Dip Liquid manufacturer supplier distributor in Mumbai, Kandla, Kolkata, Vizag, Chennai, India, Fujairah, Dubai UAE, Muscat Oman, Kenya Africa. Get the best quality of Pickling Dip Liquid at a competitive price from us. We have ready stock of Pickling Dip Liquid in India, UAE Gulf, Oman, Kenya Africa. Contact us for bulk as well as small orders.
THE UNIT COST FOR THE PRODUCT IS FEW CENTS PER SQ. FT., BUT THE ACTUAL PRODUCT COST COMES OUT BELOW ZERO AFTER USE, BECAUSE OF ELIMINATING ONE OR MORE TRADITIONAL PROCESS STEPS.
BENEFIT of Pickling Dip Liquid :
1) Complete Rust Removal on any Metal surface (Ferrous and Non-ferrous metal)
2) Long term Indoor Rust Protection (for several years)
3) Welding, including welding on Hot rolled steel without removing the Mill scale
4) Priming, Painting, Electrostatic painting, Powder coating, Epoxy coating, Ceramic coating etc.
5) Metal surface preparation for High Temperature coating, such as Epoxy Coating (oven temperature around 500°F), Ceramic coating (baking temperature around 1800°F) etc.
6) One Step De-scaling/Coating of Hot Rolled steel (mill scale) & Heat scale at room temperature.
7) Used for metal surface preparation of New metal as well as for re-painting jobs after blasting (maintenance)
8) Injection Molding – For Die manufacturers as well as Injection molding companies (both Plastic & Metal)
9) STAINLESS STEEL PASSIVATION: Complete SS passivation of Stainless Steel by a dipping process at room temperature or in heated condition (to speed up process), with Zero Waste disposal. Replaces Nitric Acid Passivation Process.
10) Rebar Coating: New Rebar can be de-scaled/condition/pickle/coated/sealed by Pickling dip Liquid Picklex in one step for better corrosion resistance during storage and also inside concrete.
Picklex 20
